Our Dual Plate Check Valve is an advanced, highly efficient flow control solution designed to prevent reverse flow and protect critical system components in piping networks. Engineered for superior performance, it features two spring-assisted semi-circular plates (discs) hinged on a central pin. This compact, wafer-style/lug-style/flange-style design is engineered to fit securely between standard ANSI/ASME or DIN or GB/T flanges,

  •    Description

    Our Dual Plate Check Valve is an advanced, highly efficient flow control solution designed to prevent reverse flow and protect critical system components in piping networks. Engineered for superior performance, it features two spring-assisted semi-circular plates (discs) hinged on a central pin. This compact, wafer-style/lug-style/flange-style design is engineered to fit securely between standard ANSI/ASME or DIN or GB/T flanges, making it an ideal choice for a vast range of applications where space, weight, and reliability are paramount.



       Working Principle

    The valve operates on a simple yet highly effective principle:

    Forward Flow: When media flows in the desired direction, the pressure of the flow forces the two hinged plates to swing open, offering minimal flow resistance.

    Flow Stopping: As forward flow velocity decreases or ceases, the built-in torsion springs assist in rapidly closing the plates.

    Reverse Flow Prevention: If backflow pressure occurs, the pressure of the reverse media and the spring force ensure immediate and tight sealing against the seal ring, effectively preventing any reverse flow and protecting upstream equipment like pumps and compressors.



       Key Design Features & Advantages

    Compact & Lightweight Design: The wafer-style construction is significantly lighter and more compact than traditional swing or lift check valves, reducing structural support requirements and overall installation costs.

    Rapid Closure & Water Hammer Mitigation: The spring-assisted closure ensures swift shutdown before flow reversal, dramatically reducing the risk of damaging water hammer phenomena.

    Low Pressure Drop: The streamlined flow path and full-port design minimize turbulence and pressure loss, enhancing system efficiency and reducing operational energy costs.

    Versatile Mounting Capability: Can be installed in horizontal or vertical pipelines (with flow direction upward), providing exceptional flexibility for various system layouts.

    Robust Construction: Manufactured from high-quality materials (e.g., Carbon Steel, Stainless Steel 316, Duplex Steel) with resilient seat seals (e.g., EPDM, NBR, Viton) to ensure long service life and compatibility with a wide spectrum of media, including water, oil, gas, steam, and aggressive chemicals.

    Maintenance-Free Operation: With no external actuators and minimal internal moving parts, these valves are designed for reliable, long-term operation with minimal maintenance needs.



       Technical Specifications

    • Design Standards: API 594, API 6D, EN 12334
    • Face-to-Face: ASME B16.10 (Wafer/Lug/Flange)
    • Flange Connection: ANSI/ASME B16.5, EN 1092-1, GB9113
    • Pressure Rating: Class 150 to Class 600 (PN10 to PN100)
    • Size Range: 2" to 48" (DN50 to DN1200)
    • Temperature Range: -40°F to +600°F (-40°C to +315°C) [Dependent on seat material]
    • End Connection: Wafer, Lugged Wafer
    • Leakage Class: API 598 (Bidirectional Zero Leakage available)



        Applications

    Our Dual Plate Check Valves are deployed across numerous industries, including:

    • Water & Wastewater: Pump discharge, pipeline systems.
    • Oil & Gas: Upstream and midstream transmission, refinery processes.
    • Chemical & Petrochemical: Handling corrosive and abrasive fluids.
    • Power Generation: Cooling water systems, feedwater lines.
    • Marine & Offshore: Seawater systems, ballast management.
    • HVAC: Heating and cooling circulation systems.



       Why Choose Our Valve?

    Our valves are precision-engineered and subjected to rigorous quality control and performance testing. We offer a combination of reliability, efficiency, and durability that is essential for protecting your capital equipment and ensuring the continuous, safe operation of your piping systems.
