1.  The three-eccentric design provides instant contact or disconnection of the disc from the saddle, which guarantees zero wear and zero leakage.
2.  The sealing ring is fully integrated into the drive, allowing replacement without dismantling the entire valve, significantly reducing maintenance costs.
3.  The sealing ring consists of laminated stainless steel metal plates and flexible graphite plates (graphito-rubber, asbestos-rubber, etc.), combining the advantages of metal rigid sealing an

  •    Description


    1.  The three-eccentric design provides instant contact or disconnection of the disc from the saddle, which guarantees zero wear and zero leakage.

    2.  The sealing ring is fully integrated into the drive, allowing replacement without dismantling the entire valve, significantly reducing maintenance costs.

    3.  The sealing ring consists of laminated stainless steel metal plates and flexible graphite plates (graphito-rubber, asbestos-rubber, etc.), combining the advantages of metal rigid sealing and elastic sealing, providing excellent sealing properties at both low and high temperatures.

    4.  The selection of suitable materials makes the valve resistant to low/high temperatures and corrosion.

    5.  The use of exclusively fire-resistant materials provides reliable fire protection.

    6.  Ease of control, low output torque, run-in disc design and low pressure loss factor make the product energy efficient.

    7.  Adjustable sealing saddle facilitates installation and maintenance; The valve can both completely cut off the flow and regulate its intensity.



       Parameters

    1. Design and manufacture according to GB/T 12238, API609, ASME B16.34, EN593
    2. Flanges: GB/T 9113, ASME B16.5, ASME B16.47, MSS SP44, GB/T 9119, GB/T 17241.6, EN1092
    3. Face to face length: GB/T 12221, API 609, ASME B16.10, EN593
    4. Test: GB/T 13927, API 598, EN12266
    5. Nominal pressure: PN100, 300Lb - 900Lb
    6. Nominal diameter: DN100-DN1200, 4"-48"
    7. Body Material: WCB, CF8, CF8M, CF3, CF3M, 4A, 5A, Inconel 625, Alloy 20, Monel, Incoloy, Hastelloy, C5, Titan, etc.
    8. Working temperature: -29℃~300℃
    9. Working environments: Water, Steam, Gas, Oil, Air etc
    10. Method of connection: Flange, Wafer, Lug Type, Butt-Weld
    11. Control mode: Lever, Worm Gear, Electric Motor, Pneumatic
