Products breif:
1. Suitable for industrial pipelines requiring minimal flow resistance and frequent operation, such as water treatment, HVAC, and general chemical processes.
2. For Water, steam, oil, natural gas, corrosive fluids

  •    Description

    1. Bidirectional Sealing

    2. Double Seal Structure with External Leakage Protection

    3. Service Life ≥ 100000 Cycles

    4. Corrosion Resistance

    5. Full-Bore Design

    6. Low Operating Torque

    7. Quick Opening/Closing

    8. No Media Stagnation Zones



      Parameters

    • Standards: API 608, API 6D, GB/T 12237, HG 3704
    • Pressure Rating: 150LB, PN10, PN16
    • Size Range: DN50-DN400 (2"-16")
    • Body Material: WCB, Stainless Steel
    • Lining Materials: PTFE, PFA, FEP, PVDF, PO, ETFE, UPE
    • Temperature Range: -29°C to +180°C
    • Working Media: Corrosive liquids and gases (e.g., H₂SO₄, HCl, HNO₃)
    • Connection Types:Flanged
    • Actuation Methods: Manual, Worm Gear, Electric, Pneumatic

    Note: Suitable for industrial pipelines requiring minimal flow resistance and frequent operation, such as water treatment, HVAC, and general chemical processes.
